Prototyping PCB Boards For AVR & PIC MCUs

by  Mengjin Su (mengjins@hotmail.com)




New: Full-speed USB, 2 in 1 (mkII & USBasp) AVR  Programmer that works with AVR Studio v4.1v5.x/v6.x under Windows 7/XP  ...
  New: How to make a logic analyzer (Saleae 8) with a prototype board.
PICkit2 kit. It's a simplified clone and compatible to the original design ...
Credit Card Size MP3 Player,based on ATtiny44 (or PIC16F688) and VS1011e ...

Other products/projects ...
'C' compiler for STM8S MCUs: click here
Pointer-less 'C' compiler (PLCC) for PIC18Fxxxx MCUs: click here
'C' compiler for Ram-less AVR MCUs: click here

PIC18A
Board size: 2.5" x 3.5"
Board style: double-side
Device supported: PIC16C83, PIC16C84, PIC16F83, PIC16F84, PIC16F627, PIC16F628, ...
Schematic document: pic18a.pdf
Price: $3.50 (price reduced)




Click here to see how to build a PIC programmer using PIC18A board ...






PIC2840D
  (NEW) (upgrade version of PIC2840A)
Board size: 3.9" x 4.7"
Board style: double-side, gold platted
Device supported: 28-pin PIC16Fxxxx, 40-pin PIC16Fxxxx, ..., 28-pin PIC18Fxxxx, 40-pin PIC18Fxxxx, ...
Schematic document: pic2840d.pdf
Price: $5.50 (price reduced)

New features on PIC2840D: USB port, LCD interface, 4 buttons, ICD2/ICSP interface, 3.3V/5V configurable, ...










AT8A
In Stock Now!
Board size: 3.0" x 3.5"
Board style: double-side, gold platted
Device supported: ATMEGA8(L), ATMEGAx8, AT4433, ...
Schematic document: at8a.pdf
Price: $4.00 (price reduced)













AT40B
(upgrade version of AT40A)
Board size: 3.7" x 4.8"
Board style: double-side, tin platted
Device supported: ATMEGA16, ATMEGA32, ATMEGA8535, AT8535 ...
Schematic document: at40b.pdf
Price: $5.50 (price reduced)


Errata document: AT40Berrata










AVR JTAG-ICE
Board size: 3.8" x 1.3"
Board style: single-side, tin platted
Device supported: ATMEGA16, ATMEGA32, ATMEGA64, ATMEGA128, ...
Schematic document: JTAG.pdf
Price: $3.00
(after assembled)










ICD2-Lite
A simplified ICD2 device that supports many PIC devices. It only has an RS232 serial interface to communicate with PC.
Board size: 4.6" x 2.7"
Board style: double-side, tin platted
Device supported: please check Microchip's web site for details
Schematic document: ICD2_1.pdf, ICD2_2.pdf
Price: $4.00 (price reduced)
  (after assembled)
Assembling instructions
Bootloader for PIC16F877A(PIC16F876A)


How to purchase boards:
  (only accept orders within US continent currently)
[1] S/H fee: $1.25 for the first board, $0.25 each for the rest.*
[2] We accept PalPal payment. You can pay for the items purchased using PayPal service. (pay to:
    mengjins@hotmail.com)
[3] Highly suggest to send an e-mail before or after paying to make sure the item is still available in stock.
[4] Checks and money orders are also acceptable.



* S/H fee will be waived if the order is or exceeds 5 PCB boards.
